Satec PM172EH series Reference Guide

42
Trigger parameter Trigger ID Unit
2
Range
1
High sliding window kvar import demand 0x160A 0.001kvar/1kvar 0 to Pmax
High sliding window kVA demand 0x160B 0.001kVA/1kVA 0 to Pmax
High accumulated kW import demand 0x160F 0.001kW/1kW 0 to Pmax
High accumulated kvar import demand 0x1610 0.001kvar/1kvar 0 to Pmax
High accumulated kVA demand 0x1611 0.001kVA/1kVA 0 to Pmax
High predicted kW import demand 0x1612 0.001kW/1kW 0 to Pmax
High predicted kvar import demand 0x1613 0.001kvar/1kvar 0 to Pmax
High predicted kVA demand 0x1614 0.001kVA/1kVA 0 to Pmax
High block kW export demand 0x1616 0.001kW/1kW 0 to Pmax
High block kvar export demand 0x1617 0.001kvar/1kvar 0 to Pmax
High sliding window kW export demand 0x1618 0.001kW/1kW 0 to Pmax
High sliding window kvar export demand 0x1619 0.001kvar/1kvar 0 to Pmax
High accumulated kW export demand 0x161A 0.001kW/1kW 0 to Pmax
High accumulated kvar export demand 0x161B 0.001kvar/1kvar 0 to Pmax
High predicted kW export demand 0x161C 0.001kW/1kW 0 to Pmax
High predicted kvar export demand 0x161D 0.001kvar/1kvar 0 to Pmax
Setpoint status
Setpoint #1 ON 0x7C00 N/A
Setpoint #2 ON 0x7C01 N/A
Setpoint #3 ON 0x7C02 N/A
Setpoint #4 ON 0x7C03 N/A
Setpoint #5 ON 0x7C04 N/A
Setpoint #6 ON 0x7C05 N/A
Setpoint #7 ON 0x7C06 N/A
Setpoint #8 ON 0x7C07 N/A
Setpoint #9 ON 0x7C08 N/A
Setpoint #10 ON 0x7C09 N/A
Setpoint #11 ON 0x7C0A N/A
Setpoint #12 ON 0x7C0B N/A
Setpoint #13 ON 0x7C0C N/A
Setpoint #14 ON 0x7C0D N/A
Setpoint #15 ON 0x7C0E N/A
Setpoint #16 ON 0x7C0F N/A
1
For parameter limits, see Note
1
to Table 4-1
2
When using direct wiring (PT Ratio = 1), voltages are transmitted in 0.1 V units, currents in 0.01 A units, and powers in
0.001 kW/kvar/kVA units. For wiring via PTs (PT Ratio > 1), voltages are transmitted in 1V units, currents in 0.01 A units,
and powers in 1 kW/kvar/kVA units.
3
The setpoint is operated when the actual phase sequence does not match the indicated phase rotation
4
The actual frequency range is 45.00 - 65.00 Hz
5
When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be
line-to-line voltages.
6
Operate limit for the voltage disturbance trigger specifies the voltage deviation allowed in percentage of the nominal
secondary line-to-line voltage. The tested voltage refers to line-to-line voltage in 3OP2 and 3OP3 wiring modes, and to line-
to-neutral voltage in other modes. See Section 5.3, Basic Setup, for information on setting the nominal voltage in your
meter.
7
Available in Version 4.93.2 or later.
Table 5-14 Setpoint Actions
Action ID
No action 0x0000
Set event flag #1 0x2000
Set event flag #2 0x2001
Set event flag #3 0x2002
Set event flag #4 0x2003
Clear event flag #1 0x2100
Clear event flag #2 0x2101
Clear event flag #3 0x2102
Clear event flag #4 0x2103
Operate relay #1
1
0x3000
Operate relay #2
1
0x3001
Increment counter #1 0x4000
Increment counter #2 0x4001
