Satec PM172EH series Reference Guide

50
Table 5-31 Data Location Codes
Location code Description
3 Data keeping memory
4 Factory setup
5 Access setup
6 Basic setup
7 Communications setup
8 Real-time clock
9 Digital inputs allocation
10 Pulse counters allocation
11 Analog output setup
12 Analog expander setup
14 Timers setup
15 Display options
16 Event/alarm setpoints
17 Pulsing setpoints
18 User assignable register map
20 Data log setup
21 Memory partitions setup
22 TOU energy registers setup
23 TOU demand registers setup
24 TOU daily profiles
25 TOU calendar
26 TOU calendar years
27 Relay control registers
28 User selectable options
31 DNP 3.0 class 0 map
32 DNP 3.0 options setup
33 DNP 3.0 events setup
34 DNP 3.0 event setpoints
35 Calibration registers
36 Time zone information
Table 5-32 Event Effect Codes
Effect code Description
0x6000 Clear energy registers
0x6100 Clear all demand registers
0x6101 Clear power demand registers
0x6100 Clear volt/ampere demand registers
0x6200 Clear TOU energy registers
0x6300 Clear TOU demand registers
0x6400 Clear all counters
0x6401-0x6404 Clear counters #1-#4
0x6500 Clear Min/Max log registers
0x6600 Clear Event log
0x6700-0x6707 Clear Data log #1-#8
0x6700 Clear all data logs
0x6800 Clear Waveform log #1
0x6900 Clear Waveform log #2
0xE100-0xE10F Setpoint #1-#16 operated
0xE200-0xE20F Setpoint #1-#16 released
0xF100-0xF10F Setpoint #1-#16 cleared
0xF500 RTC set
