The basic function of the code lock is to control access to the room where the door provided
with electric catch, bolt or electromagnetic interlock is installed. The lock may also be used
for partition control during a guard round in the facility.
In order to open the door, enter the user CODE from the lock keypad and press [#] or [
*
]. The
user must be authorized to use the particular code lock.
[CODE][#] door opening
[CODE][
*
] door opening
Note: Entering a wrong (not recognize) code three times may:
− Trigger an alarm PROG;
− block a code lock for 90 seconds. After this time each next wrong code entering will
block the code lock PROG.
The code lock keypad can be used to change the user code, the change procedure being
the same as for the partition keypad.
It is possible to call special alarms using the code lock keypad. To start these functions hold
down (for approximately 3 seconds) key labeled:
– FIRE alarm,
– AUXILIARY alarm (calling for medical aid),
– PANIC alarm.
Acknowledgement of acceptance by the control panel of the called control function (by sound
or illumination of the code lock keypad) is identical as for the partition keypad.
6.7 P
ROXIMITY CARD AND
DALLAS
CHIP READER
Using the card/chips activates control in the partition the reader is assigned to - in much the
same way as entering this type of code from a partition keypad. Presenting the card to the
reader/touching the reader with the chip is recognized by the reader in much the same way
as entering the code and confirming it by the [
*
] key in the partition keypad. Holding the
card/chip (for approx. 3s) is recognized in the same way as entering the code and confirming
it by the [#] key. The reader reaction to presenting the card/touching the reader with the chip,
or holding the card/chip, depends on the expander settings. By using the proximity
card/DALLAS chip you can:
− control the expander relay, and, by means of the expander relay, the electromagnetic door
lock, latch, lighting, actuators (ventilation, pumps, etc.);
− arm partitions;
− disarm the system and clear alarms.
The proximity card readers come with two-color LED and buzzer for communication of the
control panel with the user. The DALLAS chip heads come only with two-color LED. It is
possible for the installer to provide an additional signaling out of the head. Description of the
reader acoustic and optical signaling - see the CA-64 DR, CA-64 SR expander manuals.
Note: Reading in a wrong (not recognized by control panel) card/chip three times may:
− trigger an alarm PROG;
− block a reader for 90 seconds. After this time each next wrong card /chip reading in
will block the keypad reader PROG.
