Tests
The function allows performing various operations to check the system for correct operation.
Partitions – checking the current status of partitions accessible to the given user and
operated from the LCD keypad. The partition status is shown in the form of a suitable
symbol (character) adjacent to the number (numbers around the keypad display) which
corresponds to the partition number in the system. The installer assigns symbols
(characters) to particular situations.
It is possible to read the following information of partitions:
b – temporary partition blocking,
? – entry delay,
E – exit delay (less than 10 seconds),
e – exit delay (more than 10 seconds),
P – fire alarm
A – alarm
p – fire alarm memory
a – alarm memory
a – zone is armed,
O – violated zones,
 – zone is disarmed, zones OK.
Note: The characters shown above are default settings which can be changed. The installer
should inform how the particular states of zones and partitions will be identified on the
display.
Zones – checking the current status of each zone in partitions accessible to the particular
user. Zone status is shown in the form of a symbol (character) next to the number
(numbers around the keypad display) which corresponds to the zone number in the
system. The installer assigns symbols (characters) to particular situations. Information on
zones is displayed, depending on the control panel size, in 1, 2 or 4 (INTEGRA 128) sets
(see p. 11, description of [G
ROUP
] LEDs). On starting the function the status of zones 1–
32 is displayed. Press the X key to display the status of the next group, or the W key to
display the previous group. The amount of available information depends on the type of
detector connected to the zone. The detectors configured as 2EOL provide the most
information.
It is possible to read the following information of zones:
b – zone bypass,
l – trouble "long violation",
f – trouble "no violation",
T – tamper alarm,
A – alarm,
– zone tamper,
O – zone violation,
t – tamper alarm memory,
a – alarm memory,
 – zone OK.
Supply voltages – the function enabling power supply voltage level to be checked for
individual expanders. The display shows the expander name and approximate power
supply voltage level for the given expander.
