47
New data should be entered from the keypad by typing the correct digit at the place of the
cursor flashing. After the digit is entered, the flashing indicator moves to the next position on
the right. The cursor can also be moved by using the W and X keys.
Troubles
This function makes it possible to view the troubles which have occurred in the alarm system.
It is only accessible when the [
TROUBLE
] LED is blinking on the LCD keypad and partition
keypads. The list of possible trouble messages is included at the end of this manual
in APPENDIX A.
The name of particular element (entered by the installer) appears in messages related to
zones, expanders and keypads, in the bottom line of the display. No additional message is
displayed at the end of this function.
Note:
• If any emergency situation occurs in the system, it is necessary to report the fact
immediately to the alarm system service person, and rectify the cause of the trouble alarm.
• The troubles also include tamper information.
Events
The function makes possible to scroll the list of events stored in the control panel memory.
The events are given in the sequence order of their occurrence. The S key permits going
back to the previous event, while the T key – to the next one. If none of these keys is
depressed for a few seconds, names related to the particular event will appear on the
display, shown alternately with the event description.
The event description contains data displayed in the following format:
date – DD:MM (day:month),
time – HH:mm (hour:minute),
identifier – xxxx (four characters – IDEN) which identifies the number of zone,
partition, module, user operating the system, special symbol,
event name – text in second display line.
Description of meaning of identifiers:
Ser. user – service code,
Mst[n] [n]=1–8 user – object master code,
u [n] [n]=1–240 ordinary user of the system,
k [n] [n]=0–15 keypad – module connected to the keypad bus or virtual keypad
accessible from the program GUARDX,
0–7 numbers of keypads in the system,
8–15 numbers of keypads accessible from the program GUARDX, defined
as follows: no. of keypad to which the user computer is connected
plus 8,
DLrs keypad connected to the main board RS port, accessible from the
program DLOADX,
DLtl keypad connected to telephone line at the main board, accessible
from the program DLOADX,
e [n] [n]=0–63 expander - module connected to the expander bus (0–31 bus 1, 32–
63 bus 2),
p [n] [n]=1–32 partition,
z [n] [n]=1–128 zone,
T [n] [n]=1–64 timer,
