User Manual INTEGRA
48
Tpar partition timer,
MnPl control panel main board.
Some of event descriptions allow readout of two identifiers, for example: partition number and
zone number, keypad number and user number, etc. To read the second identifier, press the
W key. Press the key again to change the displayed identifier for the previous one. Press the
X key to display the names related to identifiers, and again to restore the event description
display. Using one of the W X keys stops the automatic changeover between displaying the
particular event description and the names related to the identifiers. Going over to a next
event (key S or T) will restore the mode of automatic changeover of the display contents.
Either viewing of all events or viewing of selected events is possible. Also, you may choose
partitions to be viewed. The selection is made for partitions controlled by the keypad and, at
the same time, accessible to the user, who called the function.
If the user wants to view selected events, he has to mark at least one event type (the
symbol must appear at the name of event type), otherwise the menu function V
IEW
is not
accessible. Marking of a partition is not necessary. When the partitions are not marked, the
list of events from all partitions accessible for the user is displayed.
Selection of partitions influences the contents of the list displayed when viewing event types
from 1 to 4 (event type numbers according to the list given below).
List of event types:
1. Zone & tamp.al. – alarms for zones, tamper alarms
2. Other alarms – other alarms. fire, auxiliary, technical alarms, no guard round.
3. Arm/Disarm/Clr – arming and disarming, alarm clearing.
4. Zone bypasses – the use of function Z
ONES BYPASSES
, bypass canceling after disarming.
5. Access control – use of keypads and proximity card readers for controlling
electromagnetic door locks, door status monitoring, temporary blocking
of partitions.
6. Troubles – technical problems in the system, restarts of modules.
7. Functions – calls for user functions to control the operation of the control panel.
8. System – service mode, clock programming, etc.
Note: The messages about the following event types are not displayed in the event lists on
the LCD keypad:
- PANIC alarm,
- Silent PANIC alarm,
- DURESS alarm.
No additional message is displayed when exiting the function.
Reset zones
This function causes a momentarily voltage loss on detector power supply outputs with
activation memory (e.g., fire detectors). This operation clears memory of detectors.
If some identical detectors are connected to a single output, the activation memory makes it
possible to find the detector which triggered the alarm.
Clear latched outputs
The function clear outputs of control panel working in the “latch" mode. It does not affect the
alarm outputs which remain active until alarm is canceled.
Some outputs in the system may work in the “latch" mode as indicators of the use of selected
codes or violation of selected zones. The “latch" type functioning prevents the activated
output from returning to its basic state until it is deactivated with the herein described
function.
