INTEGRA SATEL
53
Controlling the R
EMOTE SWITCH
type of outputs
The control is effected by means of the [#] or X key. Pressing the key will activate the output
for a preprogrammed period of time or toggle the status of the output. It depends on the
output settings. The R
EMOTE SWITCH
type of output will work similarly as the MONO
SWITCH
, if
its preset operation time is different from 0, or as the BI
SWITCH
, if the preset operation time is
equal to 0 or the L
ATCH
option has been enabled.
In case of the R
EMOTE SWITCH
type of outputs, the output status can also be displayed on the
basis of zone status, hence the meaning of displayed symbols depends on output settings:
– output inactive (off) or zone non-violated (device controlled by inactive output),
O – output active (on) or zone violated (device controlled by active output).
Note: If the output works in the same way as the MONO
SWITCH
, and its status is not
displayed on the basis of zone status, then repeatedly pressing the [#] or X key with
the output active will change the symbol displayed, but the output will remain active for
the preprogrammed period of time.
Controlling the S
HUTTER UP
and S
HUTTER DOWN
type of outputs
The S
HUTTER UP
and S
HUTTER DOWN
type of outputs are always programmed as consecutive
and in pairs. Displayed on the list of outputs is only the name of output programmed as
S
HUTTER UP
. The current status of the outputs is indicated on the display next to the output
name in the following way:
– outputs inactive (off),
Ç – S
HUTTER UP
output active (on),
È – S
HUTTER DOWN
output active (on).
Only one of the outputs can be activated at a time. After pressing the [#] or X key, a line
mark appears under the field, in which the output status is displayed. Pressing the S key will
activate the S
HUTTER UP
output (if both outputs were inactive) or toggle the S
HUTTER DOWN
output to its inactive state (if it was active). Pressing the T key will activate the S
HUTTER
DOWN
output (if both outputs were inactive) or toggle the S
HUTTER UP
output to its inactive
state (if it was active). When the control is over, press the [#] or W key to go back to the list of
controllable outputs (the line mark under the output status field will disappear).
Service mode
The function starts a special control panel operation mode and displays the list of S
ERVICE
FUNCTIONS
. The control panel does not signal alarms from most of zones (including tamper
alarms), it only responds to violation of some zones armed for 24 hours and to alarms from
partition keypads and code locks (hold-down functions). In this operation mode, the control
panel programming is possible with the use of DLOADX program via RS port (on the
mainboard) and through the telephone line. The control panel remains in the service mode
until exiting it with the E
ND OF
SM function (from the service functions list).
The function is accessible after enabling the service access by the master user and entering
the service code.
Take SM over
The function makes it possible to switch over the operation control of the control panel being
in the service mode to a keypad other than that from which the service mode was called. The
function, which is accessible to the service only, is intended for use in large facilities, with
several keypads installed, to facilitate the installer's work.
Downloading
The function which starts communication with the service computer. It allows installer to
program the alarm system by means of the computer and the DLOADX service program. It is
