User Manual INTEGRA
30
• If the option W
ARN WHILE ARMING IF TROUBLE
is enabled, the partitions are armed from the
LCD keypad and there are troubles in the system, the control panel will inform the user of
it with a suitable message before arming. Pressing the key [1] will arm the partition(s), and
pressing the key [2] will display information on troubles. Pressing the [
*
] key will make it
possible to cancel the arming and trouble review. If the key [2] was pressed, there will be
return to the question about arming or trouble viewing after the review is completed and
the [
*
] key is pressed.
• If the arming is performed by means of the LCD keypad in a partition with temporary
blocking, the control panel will ask to indicate the block time before arming.
• If the option V
IOLATED
/
BYPASSED ZONE PREVIEW WHEN ARMING
is active and the arming is
performed from the LCD keypad, the control panel will check that there are no
violated/bypassed zones. Checked for possible violation are the zones for which the
P
RIORITY
option has not been enabled. If violated or bypassed zones are found, the
following message will be displayed on the keypad: "Viol./Bypass z. 1=Arm 2=Check".
Pressing the key [1] will arm the partition, and pressing the key [2] will display information
on violated/bypassed zones. The [
*
] key will cancel the arming and viewing. If the key [2] is
pressed, the question about arming and viewing will be asked again after completion of the
viewing and pressing of the [
*
] key.
In case of zones for which the exit delay time has been programmed, the arming will take
place after the countdown ends. It is possible to terminate the exit delay countdown and arm
the partition immediately by entering [9][#] from the keypad or partition keypad PROG.
Reduction of the exit time is only possible on the same keypad/partition keypad from which
the arming was done.
Some special methods of partition arming are possible (available from the LCD keypad):
− arm without interior zones – the control panel does not respond to violation of zones
defined as internal by the installer. This possibility allows the user to stay in the facility
and arm the system. The facility is normally protected outside and the system performs
all the preprogrammed functions.
− arm without delayed zones – arming is performed in much the same way as above, but
the delayed zones additionally act as immediate ones.
To arm the system in one of the presented modes, proceed as follows:
1. Enter ACCESS CODE and press the [
*
] key.
2. Call the A
RMING MODE
function.
3. Using the S and T keys select one of the suggested arming modes and press [#].
4. Call the A
RM
function and select (highlight) the partition to be armed.
5. Press the [#] key.
Disarming the partition will reset the special mode of its arming. To re-arm the partition in a
special mode, the above mentioned procedure must be repeated.
The procedure of arming the system from a LCD keypad in the partition to which the type
(10) 24
H VIBRATION
zone belongs and the testing function of vibration sensors is activated
PROG is somewhat different.
When the arming function is called, the following message appears on the LCD display:
"Vibr. zone test xx s (1=arm)" where the xx field indicates the number of seconds before the
end of test.
During the test, the control panel is waiting for the violation of vibration zones in a given
partition. If all the vibration zones of the given zone are violated, the alarm control panel will
proceed to counting the exit delay time and arming the system. If any of the vibration zones is
