INTEGRA SATEL
61
Assuming that Partition 2 is disarmed, and Partitions 1, 3 and 4 are armed, the pattern shown on keypad display
in the graphic mode may look like the one below:
Example 3: ZONE BYPASSING
- bypass Zone No. 4 named Entrance door and Zone No 49 named PIR secr.office; the user code: 38407.
[3][8][4][0][7][*]
Enter code – calling the user function menu.
Using most of the user functions (except for the key "hold-down" and quick arming functions) starts with entering
code and pressing [
*
] (or [#] – Example 1 and 2).
T or S Scroll through the list with accessible function names. Press one of these keys as many times as
needed to display the name of proper user function next to the arrow
.
[#] or X
Select function indicated with arrow – you will be moved to the stage of selecting zones
(detectors) to be bypassed
.
T or S
Scroll through the list with zone names. Press one of these keys as many times as needed to
display the name of the first zone to be bypassed (Entrance door) next to the arrow
).
[9] Mark the
zone selected for bypassing
(
mark on the right-hand side of display) using any
numeric key
.
T or S
Scroll the list with zone names to select next zone (detector) for bypassing (PIR secretary
office).
[9] Marking of the
zone
selected for bypassing.
[#] End of selection and bypassing the status monitoring for all zones (detectors) marked).
Note: Zone bypass is cancelled after disarming of the partition to which the bypassed zones belong.
Á
Arm
Change own code
Change own code
Á
Zone bypasses
Zone bypass:
DUAL conf. room
Zone bypass:
Entrance door
Zone bypass:
Entrance door
Zone bypass:
PIR secr. office
Zones bypassed
