6 Installation of Options
133
CL4NX/CL6NX Service Manual
16 Connect the option cable ) and
cutter cable
* to the
linerless relay PCB
+. Tighten two
screws
 to attach the
linerless relay PCB.
CAUTION
To avoid electrical damage, make sure that the
orientation of the relay-PCB is placed with the
highlighted connector at the bottom as shown.
17 Attach the front cover 1 while placing
the cutter cable
* onto the slot.
5
16
18
19
17
5
Cutter cable position
17
