2 Operation and Configuration
22
CL4NX/CL6NX Service Manual
Offset
Tools > Service > Offset
Factory setting of the offset position.
Offset position refers to the tear-off position, cut position and dispense
stop position.
Set the offset value '+' to move the stop position opposite the feed direction
and value '-' to move the stop position in the feed direction.
The setting range is from -99 to 0 to 99 dots.
Note
The sum of the offset values in the Service menu and Printing menu is
the actual offset position.
Pitch
Tools > Service > Pitch
Factory setting of the print position.
Offset the print position in the vertical direction.
Set the offset value '+' to move the print position opposite the feed
direction and value '-' to move the print position in the feed direction.
The setting range is from -99 to 0 to 99 dots.
Note
The sum of the offset values in the Service menu and Printing menu is
the actual vertical print position.
