SATO CL6NX User Manual

Configuring the Driver Settings
170
• The settings of the printer driver should be done by an administrator.
(1) [Stocks]
Manages stored media. The stored media can be used from applications.
(2) [Fonts]
Defines and manages barcode fonts and command fonts. You can add, modify, and delete
definitions. Also, you can print by replacing the system fonts with the printer’s device fonts when
defining replacement fonts.
(3) [Driver Settings]
Sets whether to enable the driver settings or application settings.
(4) [Configure Printer]
Obtains and changes the settings of the connected printer.
(5) [Maintenance]
Outputs the current driver settings to a file and reads the settings.
(6) [International]
Sets the display language of the printer driver.
• Be sure to manage the master data for fonts by customer. SATO do not take
responsibility for data stored on the printer.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
