SATO CL6NX User Manual

353
Set the Bluetooth connection.
The setting items are as follows:
Enable
Enable or disable the functions for Bluetooth.
Name
Set the device name for the printer.
PIN Code
Set the PIN code.
BD Address
Shows the BD address of the printer. (You cannot change this address.)
Firm Version
Shows the firmware version of the Bluetooth. (You cannot change this value.)
Host BD Addr
Check the Host BD address.
Authentication
Set the authentication level.
ISI
Set the ISI communication parameter.
ISW
Set the ISW communication parameter.
PSI
Set the PSI communication parameter.
PSW
Set the PSW communication parameter.
CRC Mode
Set the CRC check function.
Flow Control
Set the communication protocol.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
