SATO CL6NX User Manual

[Test Print]
456
[Configure List]
Print the printer setting information.
1. Check and set the items as listed on the [Configure List] menu.
2.
Press the button to start the test print. Press the button again to pause the
print.
To stop the test print, first pause the print and then press the button.
The setting items are as follows:
Label Width
Shows the necessary media width of the test print.
The necessary media width is 50.8 mm (2") for [Small].
Label Length
Set the length of one piece of the media used for the test print.
The setting range varies depending on the print resolution of the printer.
The setting range is as follows:
Resolution CL4NX CL6NX
203 dpi
(1 dot = 0.125 mm
(0.0049"))
400 to 1600 dots 400 to 1600 dots
305 dpi
(1 dot = 0.083 mm
(0.0033"))
600 to 2400 dots 600 to 2400 dots
609 dpi
(1 dot = 0.042 mm
(0.0017"))
1200 to 4800 dots -

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
