461
Label Width
Shows the necessary media width of the test print.
The necessary media width is 101.6 mm (4") for [Large] and 50.8 mm (2") for [Small].
Label Length
Set the length of one piece of the media used for the test print.
The setting range varies depending on the print resolution of the printer.
The setting range is as follows:
Resolution CL4NX CL6NX
203 dpi
(1 dot = 0.125 mm
(0.0049"))
400 to 1600 dots 400 to 1600 dots
305 dpi
(1 dot = 0.083 mm
(0.0033"))
600 to 2400 dots 600 to 2400 dots
609 dpi
(1 dot = 0.042 mm
(0.0017"))
1200 to 4800 dots -
Pitch
Set the print position in the vertical direction.
The setting range varies depending on the print resolution of the printer.
The setting range is as follows:
Resolution CL4NX CL6NX
203 dpi
(1 dot = 0.125 mm
(0.0049"))
-30 to 0 to 30 dots -30 to 0 to 30 dots
305 dpi
(1 dot = 0.083 mm
(0.0033"))
-45 to 0 to 45 dots -45 to 0 to 45 dots
609 dpi
(1 dot = 0.042 mm
(0.0017"))
-90 to 0 to 90 dots -
When you decrease the setting value, the print position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the print position moves opposite the feed direction (toward
the end part of the media).
