483
This setting can be used to exclude first barcode(s) from the check target when multiple barcodes are
printed on each media.
The setting range varies depending on the print resolution of the printer.
The setting range is as follows:
Resolution CL4NX CL6NX
203 dpi
(1 dot = 0.125 mm
(0.0049"))
10 to 20000 dots 10 to 20000 dots
305 dpi
(1 dot = 0.083 mm
(0.0033"))
15 to 18000 dots 15 to 18000 dots
609 dpi
(1 dot = 0.042 mm
(0.0017"))
30 to 9600 dots -
[VOID Print]
Set whether to print error marks on the media when a barcode reading error or barcode comparison
error occurs.
6 x 6 mm (0.24" x 0.24") error marks are printed within the width of the print data image and in a length
of up to 30 mm (1.18") from the trailing end of the label. The length varies depending on the image
length of the print data and the operation mode.
The options are as follows:
To Next Page
