SATO CL6NX User Manual

Printing RFID Tag Errors
616
TAG NOT FOUND Error in RFID Write
Command
(1) Feed direction
(2) The dump for the first 16 or 32 bytes of the write data
The types of errors to print are as follows:
Message Cause and Countermeasure
TAG NOT FOUND
Cause
Did not find the tag to print, or failed to read the tag.
Countermeasure
Confirm the inlay operation and check the printer/antenna settings.
WRITE TAG ERROR
Cause
Failed to write the tag.
Countermeasure
Confirm the inlay operation and check the printer/antenna settings.
PROTECT (TAG) ERROR
Cause
1. Tried to write to a locked tag.
2. Tried to write to an address that is not permitted.
Countermeasure
Use media that is not locked.
VERIFY TAG ERR(OR) Only for ISO/IEC 15693, ISO/IEC 14443 Type A
Cause
The written data and read data do not match.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
