SATO CL6NX User Manual

701
Error Message 1003 (Parity Error)
When there is an error with the printer, the error message appears on the screen.
Check the cause and countermeasure, and then take appropriate action.
To clear the error:
Press the button (OFFLINE) or button, or adjust the settings.
Cause and Countermeasure
Cause (1)
RS-232C settings are incorrect.
Countermeasure (1)
Set the interface settings of the printer again.
RS-232C
Cause (2)
The RS-232C cable is not connected correctly.
Countermeasure (2)
Power off the printer, connect the RS-232C cable correctly, and then power on the printer again.
Powering On/Off the Printer
RS-232C Interface Connection (Standard)
Contact your SATO technical support center if the error cannot be resolved.
Contact Information for When You Are in Trouble

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
