SATO CL6NX User Manual

767
Basic Specifications
Protocol Status3, Status4, Status5
IP Address
• IPv4
• IPv6
Subnet Mask
• IPv4
• IPv6
Gateway Address
• IPv4
• IPv6
Data Transfer Method
802.11a
Max 54 Mbps
802.11n
Max 135 Mbps
802.11b
Max 11 Mbps
802.11g
Max 54 Mbps
• These are the logical values based on the wireless
LAN specifications and are not the actual data transfer
speeds.
Frequency Band
• 2.4 GHz (2.412 to 2.485 GHz)
• 5 GHz
Communication Channel The number of channels you can set varies depending on the
region where you use the printer.
SSID Any alphanumeric character (Maximum 32)
Authentication
• Open System
• Shared Key
• WPA/WPA2
• Perform the RADIUS server authentication using 802.1x (EAP-
TLS, LEAP, EAP-TTLS, EAP-PEAP, EAP-FAST protocol)
Encryption
• None
• WEP (64 bits/128 bits)
• AES (WPA-PSK/WPA2-PSK, WPA-802.1x/WPA2-802.1x
authentication)
Communication Mode
• Infrastructure

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
