1. AMPSEAL connector
2. Magnet symbol (for pairing)
3. Product label (Located on left and right side)
4. General label
5. External antenna
Back View
Bottom View
6. AMPSEAL connector
7. Magnet symbol (for pairing)
8. Status LED
Side View (Left)
3.2. Receiver Overview
Receiver Views
1
2 3
4 5
Hole diameter
Ø 5,5 mm
Ø 0.21 inches
104 mm
4.1 inches
6 87
49 mm
1.9 inches
118 mm
9.6 inches
138 mm
5.4 inches
125 mm
4.92 inches
118 mm
9.6 inches
To Next Page
