– 58 –
Scanreco – Service Manual G6 Radio Remote Control System
8.1.2. Spare Parts
Available spare parts are presented in alphabetical order in the table below.
• Spare parts list meanings:
P00027-Cxxxxxxx00: This item number refers to the specific customer configuration.
See the product label for your specific configuration number. Replace “xxxxxxx” with the
configuration number found on the product label.
• Serviced by:
°
Operator: The spare sparts can be replaced by the operator.
°
Service Point: The spare sparts must be replaced by an authorized service technician.
Item number Description Product Serviced by
49070 Antenna Omni 2.4 - 2.485 GHz RP-SMA Male Receiver Operator
102890 Antenna Omni 868/915/2400 MHz RP-SMA Male Receiver Operator
103216 Battery Charger Li-ion With Car Adapter 12/24 VDC System Operator
102242 Battery Charger Li-ion With Flying Leads 12/24 VDC System Operator
103217 Battery Charger Li-ion With Power Supply 110-230 VAC System Operator
103141 Battery Charger NiMH With Car Adapter 12/24 VDC System Operator
102232 Battery Charger NiMH With Flying Leads 12/24 VDC System Operator
103142 Battery Charger NiMH With Power Supply 110-230 VAC System Operator
701 Battery Li-Ion 5100 mAh 7.2 VDC Black Scanreco Logo System Operator
700 Battery NiMH 2000 mAh 7.2 VDC Grey Scanreco Logo System Operator
102421 Bottom Section SA Micro Black With Stop Button Micro Service Point
102466 Bottom Section SA Micro Black With Stop Button &
Hirschman Tether Connector
Micro Service Point
102422 Bottom Section SA Micro Black With Stop Button & M12
Tether Connector
Micro Service Point
102444 Bottom Section SA Mini Black Mini Service Point
102470 Bottom Section SA Mini Black With Hirschman Tether
Connector
Mini Service Point
102443 Bottom Section SA Mini Black With M12 Tether Connector Mini Service Point
102442 Bottom Section SA Mini Black With Stop Button Mini Service Point
102468 Bottom Section SA Mini Black With Stop Button &
Hirschman Tether Connector
Mini Service Point
102441 Bottom Section SA Mini Black With Stop Button & M12
Tether Connector
Mini Service Point
102545 Cable Assembly 10-pole 2-axis joystick Micro/Mini Service Point
102546 Cable Assembly 10-pole 3-axis joystick Micro/Mini Service Point
103155 Cable Assembly 10-pole Micro Bottom Micro Service Point
102561 Cable Assembly 10-pole Mini Bottom Mini Service Point
102552 Cable Assembly 10-pole Safe Digitals Micro/Mini Service Point
102550 Cable Assembly 11-pole Encoder, LED Micro/Mini Service Point
102549 Cable Assembly 13-pole Digitals Micro/Mini Service Point
103618 Cable Assembly TE Connectivity AMPSEAL 14-pol
AWG 20 3.24 m
Receiver Service Point
102554 Cable Assembly 3-pole Stop Button Micro/Mini Service Point
102547 Cable Assembly 4-pole L2 Lever Micro/Mini Service Point
