– 46 –
Scanreco – Service Manual G6 Radio Remote Control System
Code Cause of error Possible reason Correction
9504 The receiver application was
unable to read time and date
from the RTC module.
No hardware support for RTC.
Hardware error.
The RTC battery service life
has expired.
Make sure that the receiver is
equipped with RTC. Disable
the RTC parameters if it is not
supported.
Replace the receiver if the
error continues.
9505 The RTC time has been
changed when RTC was
initialized.
The time has been changed.
The RTC battery service life
has expired.
Replace the receiver if the
error continues.
9801 – 9899 A minor transmitter software
error has been found.
Software error.
Hardware error.
Update the transmitter
software.
Replace the main board if
error continues.
7.2. Self-test Mode
Use Self-test mode to diagnose errors in actuators on the customizable area of the transmitter.
Self-test mode is started from the information center display. The purpose is to either identify
a broken actuator or rule out errors in actuators. If no errors are found, further troubleshooting
is required.
When starting the Self-test mode, all digital and analog data will be visible on the information
center display and on the color display, if the transmitter is equipped with a color display. The
displays will allow users to monitor data in real-time during testing. For the color display there will
also be several screens that display dierent kinds of data. To switch between them press the
Confirm button (right side of the information center display).
NOTICE!
Before testing, set rotary potentiometers to zero-position.
