– 33 –
Scanreco – Service Manual G6 Radio Remote Control System
6.2.1. Antenna
The receiver has an external antenna that is connected to the receiver with a RP-SMA
connector. If the antenna needs replacing, make sure to use an antenna for the matching
frequency (Maximum gain is 2 dBi for 2.4 GHz and +1 dBi for 868/915 MHz). Also, when
attaching the new antenna, tighten it with a torque of 0,3-0,6 Nm.
When the receiver is installed inside an enclosure, an extension cable can be used to place the
antenna in an optimal position. The extension cable must be a 50 Ohm coaxial low loss cable
with a maximum length of 10 meters.
6.3. Transmitter Setup
Transmitters and receivers can be delivered either as a pre-paired system or as individual parts
that will require pairing during initial setup. If the system is pre-paired the status LED on the
receiver will switch from a green continuous light to a fast-flashing green light, when starting
the transmitter.
6.3.1. Initial Pairing
To pair the transmitter and receiver, follow the instructions below.
1. Press the two buttons next to the information center display,
Next (left side) and Confirm (right side), at the same time.
2. Navigate to option 2 and press Confirm.
3. Optional: The option to cancel pairing will be shown on the screen.
If you want to cancel the pairing process press Next to return to
the main screen. Otherwise continue to the next step.
4. Press and hold down the buttons Next + Confirm at the same
time for 3 seconds.
5. The transmitter will start searching for receivers.
6. Start pairing mode on the receiver.
a. Switch o the receiver.
b. Switch on the receiver.
c. Within five seconds after switching on the receiver, place the
pairing magnet on the magnet symbol. The pairing magnet is
supplied with every system delivery. If you do not have the
pairing magnet, you can use any magnet with a force greater
than 1 kg.
d. The LED on the receiver will flash orange with fast pulses,
indicating that pairing is pending.
e. Immediately remove the magnet.
2
125
104
(4x)
5,5
This document is our property. It must not be copied and its contents
must not be imparted to third persons without our written permission.
Infringement of the above will be prosecuted.
Där ej annat anges
Where not specified
Ritad av
Dwn By
Godk.
Appr.
Skala
Scale
Ersätter
Replacing
Filnamn
File Name
Ritn.nr/ Dwg. No.
Dat.
Date
Volym
Volume
Vikt
Weight
Dat.
Date
-
-
-
-
ISO 2768-m
-
-
1:1
-
-
SCANRECO
RADIO REMOTE CONTROL SYSTEM
RoHS compliant
