Scanreco – Service Manual G6 Radio Remote Control System
PART 1: TECHNICAL INFORMATION
1. Introduction
The G6 Micro or Mini transmitter together with a G6 CAN receiver makes a complete Scanreco
G6 radio remote control system. This system has been developed for professional usage in
various safety critical applications in construction and industrial settings. The Scanreco G6 radio
remote control system oers numerous configuration possibilities to suit dierent machines and
operator preferences.
This service manual has been created for the use by qualified personnel with a technical
background at machine producers, system integrators and distributors. Do not distribute to,
or share with, end customers and / or machine operators.
It is the buyer's responsibility to train end customers and machine operators on the correct and
safe usage of the Scanreco G6 radio remote control system, wherein no liability for improper use
and implementation falls upon Scanreco.
Furthermore, it is the buyer’s responsibility to write a complete manual for operators that covers
both the machine itself and the functionality and usage of the Scanreco G6 radio remote control
system. To assist in the creation of the complete manual for operators, Scanreco provides a generic
user manual for the radio remote control system stand-alone.
This service manual is intended as a professional guideline when installing, troubleshooting,
and servicing the products. It is intended to be generic, describing the Scanreco G6 platform
of products, and your specific configuration may not contain all the elements described herein.
See Scanreco technical specification or technical documentation provided by the system
installer or machine producer for more information regarding individual system setups.
1.1. Scanreco Integrated Safety Platform (SISP
TM
)
The system is equipped with a third party approved safety solution that monitors all safety
classified functions. Dual microprocessors in both the transmitter and receiver will verify safe
and correct functionality. This is a first of its kind modular safety solution invented by Scanreco
in accordance to IEC 61508 and ISO 13849-1 safety standards.
1.2. Product Labels
Both the transmitter and receiver have product labels. It is important to use the part and
serial / batch numbers in all communication with your point of purchase or Scanreco.
NOTICE!
• Always document the product serial number found on the product label for both the transmitter
and receiver. This will make traceability easier and help to identify which products that are
associated with which machine.
• When exporting products outside of Europe and North America additional country specific
approvals and labels will be needed. Contact your point of purchase or Scanreco for further
information.
• Do not remove or cover these labels.
