Scanreco – Service Manual G6 Radio Remote Control System
Item number Description Product Serviced by
102476 E-Board Transceiver TR06 PCU Mini G6 2.4 GHz
External Antenna
Mini Service Point
102437 E-Board Transceiver TR06 PCU Mini G6 868/915 MHz/
2.4 GHz G External Antenna
Mini Service Point
102260 Gasket Thermoplastic Black Micro Service Point
102301 Gasket Thermoplastic Black Mini Service Point
102511 Joystick 1-axis Micro/Mini Service Point
102592 Joystick 1-axis With Push Button Micro/Mini Service Point
102505 Joystick 2-axis Square Gated Micro/Mini Service Point
102507 Joystick 2-axis Square Gated With Push Button Micro/Mini Service Point
102506 Joystick 3-axis X-Y-Z Square Gated Micro/Mini Service Point
47600 Lever L2B Black Micro/Mini Service Point
48412 Lever L2B Red Micro/Mini Service Point
100709 Lever Rotational ±135° – Safety Potentiometer
Bi-directional
Micro/Mini Service Point
100708 Lever Rotational 270° – Safety Potentiometer
Uni-directional
Micro/Mini Service Point
52021 Lid For Protective Frame Mini Operator
103157 M12 Lid With Strap For Tether Connector Micro/Mini Operator
103169 Magnet Shaft Mounted 21xx25 mm For Pairing Receiver Operator
102464 Mounting Kit Joystick Micro/Mini Service Point
102530 Mounting Kit Elevated Joystick Micro/Mini Service Point
102458 Mounting Kit Lever L2 Micro/Mini Service Point
49409 Plastic Knob Black – 13 mm For Non-Safety Potentiometers Micro/Mini Operator
49410 Plastic Lid Black For Knob 49409 Micro/Mini Operator
49411 Plastic Nut Cover Black For Knob 49409 Micro/Mini Operator
45106 Plastic Knob Black – 21 mm For Non-Safety Potentiometers Micro/Mini Operator
45107 Plastic Knob Lid Black For Knob 45106 Micro/Mini Operator
100453 Plastic Knob Black For Non-Safety Rotary Switches Micro/Mini Operator
100454 Plastic Lid Black For Knob 100453 Micro/Mini Operator
103089 Plastic Knob Black For Safety Potentiometers And Safety
Rotary Switches
Micro/Mini Operator
103090 Plastic Lid Black For Knob 103089 Micro/Mini Operator
45007 Plastic Rubber Hood Button Black Micro/Mini Service Point
102524 Plastic Rubber Hood Button Black – Side Button Micro/Mini Service Point
45609 Plastic Rubber Hood Button Green Micro/Mini Service Point
45607 Plastic Rubber Hood Button Red Micro/Mini Service Point
45608 Plastic Rubber Hood Button Yellow Micro/Mini Service Point
44510 Plastic Rubber Hood Toggle Black Micro/Mini Service Point
52025 Plastic Rubber Hood Toggle Black – Half Booth Micro/Mini Service Point
45448 Plastic Rubber Hood Toggle Black/Silver – Half Booth
Latching Toggles
Micro/Mini Service Point
49485 Plastic Rubber Hood Toggle Black/Black – Half Booth
Latching Toggles
Micro/Mini Service Point
51294 Plastic Rubber Hood Toggle Green Micro/Mini Service Point
52180 Plastic Rubber Hood Toggle Grey Micro/Mini Service Point
