BASCSOUL_EN
V02 | 10.2017
19
www.schaerer.com
Product description
We reserve the right to make technical changes.
* For special equipment, see serial plate. The values specified here apply to the standard equipment.
** The A-weighted noise level (slow) and Lpa (impulse) at the workplace of the operating personnel is below
70 dB (A) for every operating mode.
3.5 Serial plate
3.6 Beverage types and output
Depending on the machine variant and options, the following beverages can be prepared:
Test overpressure 24 bar 24 bar
Capacities
Drinking water capacity Mains water supply
Bean hopper capacity per ±1200 g
Grounds container capacity 60 – 70 coffee cakes
External dimensions
Width without optional accessories 330 mm
Width with cooling unit 723 mm
Height including bean hopper and key 761 mm
Depth 600 mm
Weight
Empty weight ±55 kg
Noise level
Continuous sound pressure level <70 dB (A)
Overpressure Steam boiler Hot water boiler
The serial plate is located on the front side of the machine behind the right-hand housing:
► Pull the grounds container a bit out of the machine for better accessibility.
► Unfold the right housing section next to the grounds container.
► In the event of a fault or warranty claim, give the information on the serial plate.
If the front serial plate is no longer legible, there is a second serial plate on the rear interior of the machine. It can
only be accessed by the service technician.
