Installation and commissioning
4.4 Installation
4.4.1 Unpacking the machine
► Unpack the machine.
► Check the remaining package contents for accessories.
► Remove the accessories supplied in the grounds container and water tank.
► Keep the original packaging in case the equipment needs to be returned.
4.4.2 Power supply connection
SCSoul up to 16 A (2600 W – 3600 W)
Option: From 16 A (4700 W – 6400 W)
Water inlet temperature
Minimum: 10°C
Maximum: 30°C
Read the "Setting up the coffee machine" and "Power supply" chapters carefully before installing.
For better access, position the back of the machine about 5 cm over the support plate.
► Remove rear sheet (without tools).
► Insert the power cable plug into the lower back of the machine.
► Insert the power plug into the building power socket.
Machine interfaces [A]:
For better access, position the back of the machine about 5 cm over the support plate.
