Operation
Option: Under-machine cooling unit
► Open doors.
► Switch toggle switch [A] to position [I].
► Press and hold button [B] for ±3 sec.
The device is switched on.
Temperature setting:
► Press and hold button [C] until the current temperature flashes.
► Increase the set temperature using the [B] button or reduce using the setting button [D].
► Button [C] saves the setting.
► Close the door.
A detailed description of the side cooling unit can be found in the supplied installation, operating and maintenance
handbook of the side cooling unit.
See also "Operation" - "Filling and connecting" - "Milk".
The following connections are required:
• Mains connection
• Control cable connection
► Connect to the mains with an apparatus cable (plug/coupling).
The connection, the cooling unit control cable to the machine, must be attached by the service technician.
