IO-Link Data Dictionary SCPSi series
21.10.01.00065/02 29.08.2014
J. Schmalz GmbH
Aacher Straße 29, D 72293 Glatten
Tel.: +49(0)7443/2403-0
Fax: +49(0)7443/2403-259
info@schmalz.de
155 0x009B 1 byte ro Air consumption of last suction cycle (unit: 1 %)
156 0x009C 2 bytes ro Air consumption of last suction cycle (unit: 0.1 Nl)
157 0x009D 2 bytes ro Energy consumption of last suction cycle (unit: 1 Ws)
160 0x00A0 2 bytes ro Leakage of last suction cycle (unit: 1 mbar/sec)
161 0x00A1 2 bytes ro Last measured free-flow vacuum (unit: 1 mbar)
162 0x00A2 1 byte ro Quality of last suction cycle (unit: 1 %)
163 0x00A3 1 byte ro Last measured performance level (unit: 1 %)
131 0x0083 228 bytes ro Newest 38 entries in the diagnostic buffer (encoding see table below)
132 0x0084 6 bytes ro Newest entry in the diagnostic buffer (encoding see table below)
133 0x0085 100 bytes ro
Newest 10 entries in the EPC data buffer
(encoding see table below)
134 0x0086 10 bytes ro
Newest entry in the EPC data buffer (saved at last autoset)
(encoding see table below)
Air consumption per cycle
EPC data buffer (all entries)
Quality
Leakage rate
Free-flow vacuum
Diagnostic buffer (newest)
Energy Monitoring [EM]
Energy consumption per cycle
EPC Data Buffer
EPC data buffer (newest)
Performance
Diagnostic buffer (all entries)
Predictive Maintenance [PM]
Diagnostic Buffer
Air consumption per cycle in percent
J. Schmalz GmbH
7 of 11 SCPSi Data Dictionary
