IO-Link Data Dictionary SCPSi series
21.10.01.00065/02 29.08.2014
J. Schmalz GmbH
Aacher Straße 29, D 72293 Glatten
Tel.: +49(0)7443/2403-0
Fax: +49(0)7443/2403-259
info@schmalz.de
40 0x0028
1 byte (V1.0)
4 bytes (V1.1)
ro Copy of currently active process data input
41 0x0029
1 byte (V1.0)
2 bytes (V1.1)
ro Copy of currently active process data output
64 0x0040 2 bytes ro Current vacuum level (unit: 1 mbar)
66 0x0042 2 bytes ro Supply voltage as measured by the device (unit: 0.1 Volt)
65 0x0041 2 bytes 0 - 99 rw 0 Pressure value from external pressure sensor (unit: 0.1 bar)
130 0x0082 Exx 1 byte ro 1-99 = Error code displayed by the device
140 0x008C cc1 4 bytes ro Total number of suction cycles
141 0x008D cc2 4 bytes ro Total number of times the suction valve has been switched on
146.0 0x0092 1 Bit ro 1 = Valve protection active
146.1 0x0092 1 Bit ro 1 =Evacuation time t1 above limit [t-1]
146.2 0x0092 1 Bit ro 1 = Leakage rate above limit [-L-]
146.3 0x0092 1 Bit ro 1 = H1 not reached in suction cycle
146.4 0x0092 1 Bit ro 1 =Free-flow vacuum > (H2-h2) but < H1
146.5 0x0092 1 Bit ro 1 = Primary voltage US outside of optimal range
146.6 0x0092 1 Bit ro unused
146.7 0x0092 1 Bit ro 1 = Input pressure outside of operating range
147 0x0093 1 byte ro
0 = no actual value
1 = Leakage of last suction cycle is >200mbar/s
2 = Leakage of last suction cycle is between 133 … 200mbar/s
4 = Leakage of last suction cycle is between 67 ... 133mbar/s
8 = Leakage of last suction cycle is <67mbar/s
148 0x0094 2 bytes ro Time from start of suction to H2 (unit: 1 ms)
149 0x0095 2 bytes ro Time from H2 to H1 (unit: 1 ms)
Process Data Out Copy
Process Data In Copy
Condition monitoring
Condition monitoring
Condition monitoring
Valve operating counter
Condition monitoring
Condition monitoring
Condition monitoring
Active error code
Condition monitoring
Counter
Vacuum-on counter
Evacuation time t
1
Condition Monitoring [CM]
Observation
Leakage area
Evacuation time t
0
Condition monitoring
System vacuum
Supply voltage
Input pressure
Error
Diagnosis
J. Schmalz GmbH
6 of 11 SCPSi Data Dictionary
