3-3
© 2014 SeaStar Solutions Optimus 360 Installation Supplement, Rev. B
Joystick Types
There are two types of joysticks: master and additional station. Every
installation must have at least one master joystick, which comes
factory configured for the number of engines in the installation. The
master joystick can be installed at any control station – the joystick
type is independent of the joystick station.
If there is no master joystick in the system you will get a persistent
“Missing Master Joystick” warning on the CANtrak display. Similarly,
if the master joystick type doesn’t match the configured number of
engines, the CANtrak will display a persistent “Invalid Joystick
Configuration” warning.
Table 3-3 lists the available joysticks at the time of printing.
3.3.1
3.3 Installing the Joystick
Install the joystick on the dash in an area that allows convenient,
unobstructed access. Whenever possible, mount the joystick on a
horizontal surface in a location that will minimize water spray.
Install the joystick using the hardware provided in the kit. The joystick
harnesses must be strain relieved to one of the mounting studs
using the cable tie provided with the joystick hardware.
A dash cutout template is provided in Appendix A.
JOYSTICK PART NO. DESCRIPTION
EJ1400 Joystick, Master, Twin Engine
EJ1403 Joystick, Master, Triple Engine, Tiebar
EJ1404 Joystick, Master, Quad Engine, Tiebar
EJ1401 Joystick, Additional Station
Table 3-3. Available joysticks.
