7-1
© 2014 SeaStar Solutions Optimus 360 Installation Supplement, Rev. B
7.0 YAMAHA
To complete the system installation for a Yamaha DEC engine you need to:
1. Connect the gateway harness to the Yamaha remote control
(section 7.1).
2. Install the Optimus EST gateway (section 7.2)
3. Complete the CAN network connections (section 7.3)
4. Configure the gateway (section 7.4)
Once you’ve completed these steps you can move on to sea trial
(Book 50) and then to the joystick setup in section 9.
The EST Gateway harness (CM20023) connects to the Lever Position
Sensor (LPS) and station status indicator (LED) harnesses at the
remote control binnacle. These connections are illustrated in the
figures that follow. Although a twin-engine remote control is shown,
the connections are identical for a triple-engine control. Additional
harness connections are shown in the schematic diagrams in
section 7.3.
If the remote control is not yet installed, ignore the instructions
regarding removal from the dash.
1. Ensure the power is switched off to the system.
2. Remove the two screws securing the binnacle cover. (Refer to
gure 7-1.)
3. Remove the four screws that mount the control head binnacle to
the dash. (Refer to figure 7-1.)
7.1 Yamaha Remote Control Connections
NOTICE
