Seastar Solutions Optimus 360 Installation Manual

8-3
© 2014 SeaStar Solutions Optimus 360 Installation Supplement, Rev. B
8.2 Yanmar and Optimus 360 CAN2
Interconnection
The Yanmar BY2/BY3 shift and throttle system and the Optimus 360
system communicate over the CAN2 network. The interconnection is
made by connecting the Yanmar CE10803 harness to the Optimus
CAN2 network at a hub or tee. See figure 8-2 and figure 8-3 for
detailed interconnection schematics.
The NMEA 2000 backbone shown in figure 8-2 and figure 8-3 has a
12 Volt power connection. If there is an existing NMEA 2000
network already powered do not make this 12 V connection. Check
NMEA 2000 network architecture and ensure correct backbone
termination.
