Seastar Solutions Optimus 360 Installation Manual

8-4
© 2014 SeaStar Solutions Optimus 360 Installation Supplement, Rev. B
RUN
OFF
OPTIMUS CAN2
OPTIMUS CAN1
CAN3
IGNITION
YANMAR HARNESS
PURPLE x 2
TERMINATOR
CM10052
TERMINATOR
CM10052
JOYSTICK
PCM
STARBOARD ENGINE
(YANMAR ZT STENDRIVE
ONLY)
i8150S
(YANMAR)
TERMINATOR
CM10055
(YANMAR)
ED1700
COLOR
CANtrak
i5601E
DISPLAY
(YANMAR)
i5601E
DISPLAY
(YANMAR)
I6800
CONTROL
HEAD
HELM
CM100xx
CM100xx (OPT.)
CM100xx
CM204xx
CM20064
CM20064
CM10001
CM20503
CM20304
CM10803
ADAPTER HARNESS
(YANMAR)
HELM HARNESS
E50100
(YANMAR)
HELM HARNESS
E50100
(YANMAR)
BOAT HARNESS CE504xx (YANMAR) BOAT HARNESS CE504xx (YANMAR)
CM20406
THIRD PARTY
NMEA 2000 DEVICES
PORT ENGINE
(YANMAR ZT STENDRIVE
ONLY)
i8150S
(YANMAR)
TERMINATOR
CM10055
(YANMAR)
HARNESS CE50206
(YANMAR)
HARNESS CE50206
(YANMAR)
NOTES:
1. xx INDICATES LENGTH IN FEET,
SEE ORDERING GUIDE.
2. NOT ALL CONNECTIONS ON
YANMAR HARNESSES ARE SHOWN,
SEE YANMAR INSTALLATION
MANUAL.
DISCRETE WIRES
FOR:
FUEL TANK 1
FUEL TANK 2
PADDLE WHEEL
TRIM POSITION
GEAR LUBE
DISCRETE WIRES
FOR:
FUEL TANK 1
FUEL TANK 2
PADDLE WHEEL
TRIM POSITION
GEAR LUBE
IGNITION
SWITCH PANEL
P S
CM20503
GREY
RED
BLACK
HA5492 NMEA 2000
COM KIT
12 VOLT
POWER
Figure 8-2. Yanmar CAN wiring diagram. (PCM mounted forward.)
