Seastar Solutions Optimus 360 Installation Manual

B-7
© 2014 SeaStar Solutions Optimus 360 Installation Supplement, Rev. B
Figure B-6.
B.3.3 STEP 1 – Import Engine-Specific Settings
On the Setup tab of the Joystick interface, click Import Engine
Specific Settings. A dialog will pop up, click Yes to confirm.
A file selector will open. From the engine(s) listed, choose the one
that matches yours and click Open. Click Yes at the dialog prompts
to write and confirm the imported settings.
NOTICE
B.3.4 STEP 1a – System
Return to the Setup tab. Set the Joystick Instance to either Main or
Second. In most cases you will be doing the setup with the main
joystick.
Figure B-7. The System parameters section of the Setup tab.
B.3.5 STEP 2 – Set Throttle Limits
In this step you will configure:
•themaximumthrottlepercentatwhichtheenginesareatidleand
•themaximumthrottlepercentintendedforjoystickuse.
Perform this step with the boat safely secured, or in an open area.
If you are having problems getting an engine to idle, or if it is idling
intermittently at different RPMs, confirm that your engine’s throttle
position sensor (TPS) is functioning properly.
