Seastar Solutions Optimus 360 Installation Manual

8-2
© 2014 SeaStar Solutions Optimus 360 Installation Supplement, Rev. B
ALL ELECTRICAL CONNECTIONS AND HARNESS MUST COMPLY
WITH ABYC WIRING STANDARDS, BE RATED FOR 105°C (221°F),
AND COMPLIANT WITH SAEJ1128.
WARNING
Figure 8-1. Independent trim switch wiring.
CONTROL HEAD
DIODE PACKS
(INCLUDED IN HARNESS)
GN RD BL BL / WH
RD / WH GN / WH
TO SECOND
STATION
(OPTIONAL)
SPLICE
TRIM HARNESS 6345518
(INCLUDED IN TILT/TRIM KIT HA5491)
HA5491 DUAL ENGINE
TILT/TRIM SWITCH KIT
AVAILABLE SEPARATELY
IF SUPPLIED BY OTHERS,
SWITCHES TO BE DP/DT,
MOMENTARY CONTACT
ON – OFF – ON
3
6
2
5
1
4
3
6
2
5
1
4
PORT ENGINE
TRIM HARNESS
TILT/TRIM KIT
HA5491
VIEWED FROM REAR OF SWITCHES
PORT SWSTBD SW
GN RD BL
STBD ENGINE
TRIM HARNESS
PORT
ENGINE
TRIM
GN RD BL
STBD
ENGINE
TRIM
FOR TRIPLE ENGINE APPLICATIONS
THE CENTER ENGINE TRIM CONNECTION
REQUIRES TRIPLE ENGINE HARNESS
6345517 (ORDERED SEPARATELY)
WIRE COLOR LEGEND
TRIM UP
TRIM DOWN
POWER
BLUE
GREEN
RED
