Device overview • 11
English
3
USB interface
For connecting a USB memory stick (contained in the scope of delivery)
for administering the following data:
• creating seca patient files on the device
• loading seca patient files from the seca 115 PC software supplied onto
the USB memory stick; calling up data on the device
• saving measured results to the USB memory stick
• reading out log files from the device (administrator function)
4
Pair of hand electrodes, right
3 pcs. with finger spacers, for bioimpedance measurement
The patient selects an electrode pair depending on their height
5
Spirit level Shows whether the device is horizontal
6
Pair of foot electrodes, right For heels and balls of feet, for bioimpedance measurement
7
Pair of foot electrodes, left For heels and balls of feet, for bioimpedance measurement
8
Pair of hand electrodes, left
3 pcs. with finger spacers, for bioimpedance measurement
The patient selects an electrode pair depending on their height
9
Foot screws, right 2 pcs, for precise alignment of the device
10
Power pack connection For connecting the power pack
11
Ethernet interface For integrating the device in a PC network
12
Foot screws, left 2 pcs, for precise alignment of the device
No. Control Function
