1.8
SEL-351S Relay Instruction Manual Date Code 20080103
Introduction and Specifications
Hardware Connection Features
Figure 1.4 Extra I/O Board (Model 0351Sx1, Screw-Terminal Block Version;
Main Board Shown in Figure 1.2)
OUTPUT CONTACTS:
If the output contacts are high-
current interrupting output contacts,
they are polarity dependent. See
Tab le 1 .1 for information on SEL-351S
models with the high-current
interrupting output contact option.
See Output Contacts on page 2.16 for
more information on the polarity
dependence of high-current
interrupting output contacts.
OUT208
OUT207
OUT206
OUT205
OUT204
OUT203
OUT202
OUT201
B01
B02
B04
B03
B07
B06
B09
B10
B08
B05
B12
B11
B15
B14
B13
B16
PROGRAMMABLE OPTOISOLATED INPUTS
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
OUT210
OUT209
OUT211
B22
B21
B20
B19
B18
B17
OUT212
B24
B23
B40
B39
B38
B37
JUMPER CONFIGURABLE
PROGRAMMABLE OUTPUT CONTACTS
IN
201
IN
202
IN
203
IN
204
IN
205
IN
206
IN
207
IN
208
