SELOGIC Control Equations
Many of the protection and control element logic inputs shown in the various
figures in Section 3: Overcurrent, Voltage, Synchronism Check, Frequency,
and Power Elements–Section 8: Breaker Monitor, Metering, and Load Profile
Functions are SEL
OGIC control equations (labeled SELOGIC Settings in most
of the figures).
SEL
OGIC control equations are set with combinations of Relay Word bits to
accomplish such functions as:
➤ Tripping circuit breakers
➤ Assigning functions to optoisolated inputs
➤ Operating output contacts
➤ Torque-controlling overcurrent elements
➤ Switching active setting groups
➤ Enabling/disabling reclosing
Traditional or advanced custom schemes can be created with SEL
OGIC control
equations.
SELOGIC Control
Equation Operators
SELOGIC control equation settings use logic similar to Boolean algebra logic,
combining Relay Word bits together using one or more of the six SEL
OGIC
control equation operators listed in Table G.3 .
Operators in a SEL
OGIC control equation setting are processed in the order
shown in Table G.3.
SELOGIC Control Equation Parentheses Operator ( )
More than one set of parentheses ( ) can be used in a SELOGIC control
equation setting. For example, the following SEL
OGIC control equation setting
has two sets of parentheses:
SV7 = (SV7+IN101)*(50P1+50N1)
In the above example, the logic within the parentheses is processed first and
then the two parentheses resultants are ANDed together. The above example is
from Figure 7.27. Parentheses cannot be nested (parentheses within
parentheses) in a SEL
OGIC control equation setting.
Ta b le G. 3 S EL OGIC Control Equation Operators (Listed in Processing Order)
Operator Logic Function
/ rising edge detect
\ falling edge detect
() parentheses
!NOT
*AND
+OR
