Sel SEL-351S - Relay Word Bits (Used in SELOGIC Control Equations)

9.27
Date Code 20080103 Instruction Manual SEL-351S Relay
Setting the Relay
Relay Word Bits (Used in SEL
OGIC Control Equations)
Relay Word Bits (Used in SELOGIC Control Equations)
Relay Word bits are used in SELOGIC control equation settings. Numerous
SEL
OGIC control equation settings examples are given in Section 3:
Overcurrent, Voltage, Synchronism Check, Frequency, and Power Elements
through Section 8: Breaker Monitor, Metering, and Load Profile Functions.
SEL
OGIC control equation settings can also be set directly to 1 (logical 1) or 0
(logical 0). Appendix G: Setting SEL
OGIC Control Equations gives SELOGIC
control equation details, examples, and limitations.
The Relay Word bit row numbers correspond to the row numbers used in the
TAR command [see TAR Command (Display Relay Element Status) on
page 10.34]. Rows 0 and 1 are reserved for the display of the two front-panel
target LED rows (See Table 10.6 ).
Ta b l e 9. 6 S E L - 35 1 S R e l ay Wo r d B its (Sheet 1 of 3)
Row Relay Word Bits
2
50A1 50B1 50C1 50A2 50B2 50C2 50A3 50B3
3
50C3 50A4 50B4 50C4 50AB1 50BC1 50CA1 50AB2
4
50BC2 50CA2 50AB3 50BC3 50CA3 50AB4 50BC4 50CA4
5
50A 50B 50C 51P1 51P1T 51P1R 51N1 51N1T
6
51N1R 51G1 51G1T 51G1R 51P2 51P2T 51P2R 51N2
7
51N2T 51N2R 51G2 51G2T 51G2R 51Q 51QT 51QR
8
50P1 50P2 50P3 50P4 50N1 50N2 50N3 50N4
9
67P1 67P2 67P3 67P4 67N1 67N2 67N3 67N4
10
67P1T 67P2T 67P3T 67P4T 67N1T 67N2T 67N3T 67N4T
11
50G1 50G2 50G3 50G4 50Q1 50Q2 50Q3 50Q4
12
67G1 67G2 67G3 67G4 67Q1 67Q2 67Q3 67Q4
13
67G1T 67G2T 67G3T 67G4T 67Q1T 67Q2T 67Q3T 67Q4T
14
50P5 50P6 50N5 50N6 50G5 50G6 50Q5 50Q6
15
50QF 50QR 50GF 50GR 32VE 32QGE 32IE 32QE
16
F32P R32P F32Q R32Q F32QG R32QG F32V R32V
17
F32I R32I 32PF 32PR 32QF 32QR 32GF 32GR
18
27A1 27B1 27C1 27A2 27B2 27C2 59A1 59B1
19
59C1 59A2 59B2 59C2 27AB 27BC 27CA 59AB
20
59BC 59CA 59N1 59N2 59Q 59V1 27S 59S1
21
59S2 59VP 59VS SF 25A1 25A2 3P27 3P59
22
81D1 81D2 81D3 81D4 81D5 81D6 27B81 50L
23
81D1T 81D2T 81D3T 81D4T 81D5T 81D6T VPOLV LOP
24
SFAST SSLOW IN106 IN105 IN104 IN103 IN102 IN101
a
25
LB1 LB2 LB3 LB4 LB5 LB6 LB7 LB8
26
LB9 LB10 LB11 LB12 LB13 LB14 LB15 LB16
27
RB1 RB2 RB3 RB4 RB5 RB6 RB7 RB8
28
RB9 RB10 RB11 RB12 RB13 RB14 RB15 RB16
29
LT1 LT2 LT3 LT4 LT 5 LT6 LT7 LT8
30
LT9 LT10LT11LT12LT13LT14LT15LT16
