Date Code 20080103 Instruction Manual SEL-351S Relay
SEL-351S Relay
Command Summary
SEL-351S Relay Commands (Sheet 1 of 3)
Command Description
2AC Enter Access Level 2. If the main board password jumper is not in place, the relay prompts for the entry
of the Access Level 2 password in order to enter Access Level 2.
ACC Enter Access Level 1. If the main board password jumper is not in place, the relay prompts for the entry
of the Access Level 1 password in order to enter Access Level 1.
BAC Enter Breaker Access Level (Access Level B). If the main board password jumper is not in place, the
relay prompts the user for the Access Level B password.
BRE Display breaker monitor data (trips, interrupted current, wear).
BRE n Enter BRE W to preload breaker wear. Enter BRE R to reset breaker monitor data.
CLO Close circuit breaker (assert Relay Word bit CC).
COM
a
p Show communications summary report (COM report) on MIRRORED BITS
®
channel p (where p = A or B)
using all failure records in the channel calculations.
COM
a
p n Show a COM report for MIRRORED BITS channel p using the latest n failure records (n = 1–512, where 1
is the most recent entry).
COM
a
p m n Show COM report for MIRRORED BITS channel p using failure records m–n (m = 1–512).
COM
a
p d1 Show COM report for MIRRORED BITS channel p using failures recorded on date d1 (see DAT command
for date format).
COM
a
p d1 d2 Show COM report for MIRRORED BITS BITS channel p using failures recorded between dates d1 and d2
inclusive.
COM
a
. . . L For all COM commands, L causes the specified COM report records to be listed after the summary.
COM
a
p C Clears communications records for MIRRORED BITS channel p (or both channels if p is not specified,
COM C command).
CON n Control Relay Word bit RBn (Remote Bit n; n = 1–16). Execute CON n and the relay responds:
CONTROL RBn. Then reply with one of the following:
SRB n set Remote Bit n (assert RBn).
CRB n clear Remote Bit n (deassert RBn).
PRB n pulse Remote Bit n (assert RBn for 1/4 cycle).
COP m n Copy relay and logic settings from group m to group n (m and n are numbers 1–6).
DAT Show date.
DAT mm/dd/yy Enter date in this manner if global Date Format setting, DATE_F, is set to MDY.
DAT yy/mm/dd Enter date in this manner if global Date Format setting, DATE_F, is set to YMD.
EVE n Show event report n with 4 samples per cycle (n = 1 to highest numbered event report, where 1 is the most
recent report: see HIS command). If n is omitted (EVE command), most recent report is displayed.
EVE n R Show event report n in raw (unfiltered) format with 16 samples-per-cycle resolution.
EVE n C Show event report n in compressed ASCII format for use with the SEL-5601 Analytic Assistant.
EVE n A Show event report n with analog section only.
EVE n D Show event report n with digital section only.
EVE n M
Show event report n with communications section only.
EVE n Sx Show event report n with x samples per cycle (x = 4 or 16).
EVE n L Show event report n with 16 samples per cycle (similar to EVE n S16).
