12.10
SEL-351S Relay Instruction Manual Date Code 20080103
Standard Event Reports, Sag/Swell/Interruption Report, and SER
Standard 15/30-Cycle Event Reports
=>>EVE <Enter>
.
.
.
Out In
Currents (Amps Pri) Voltages (kV Pri) 1357 135
IA IB IC IN IG VA VB VC VS Vdc Freq 246A 246
[1]
181 -103 -92 -14 -14 14.8 -7.5 -7.5 13.8 125 60.00 .45. ...
1 158 -161 -3 -3 -0.0 13.2 -13.0 -8.0 125 60.00 .45. ...
-181 102 93 14 14 -14.8 7.4 7.6 -13.7 125 60.00 .45. ...
1 -159 161 3 3 0.1 -13.3 13.0 8.1 125 60.00 .45. ...
[2]
181 -100 -94 -14 -14 14.8 -7.3 -7.7 13.7 125 60.01 .45. ...
-2 159 -160 -3 -3 -0.2 13.3 -12.9 -8.2 125 60.01 .45. ...
-181 99 95 14 14 -14.8 7.2 7.8 -13.6 125 60.01 .45. ...
3 -160 159 3 3 0.3 -13.4 12.9 8.2 125 60.01 .45. ...
Example with variable scaling (EVE V), wye-connected:
=>>EVE V <Enter>
.
.
.
Out In
Currents (Amps Pri) Voltages (kV Pri) 1357 135
IA IB IC IN IG VA VB VC VS Vdc Freq 246A 246
[1]
181 -103 -92 -14 -14 14.8 -7.477 -7.547 13.8 123 60.00 .45. ...
0.58 158 -161 -2.81 -2.96 -0.036 13.2 -13.0 -7.956 123 60.00 .45. ...
-181 102 93 14 14 -14.8 7.375 7.644 -13.7 123 60.00 .45. ...
0.73 -159 161 2.71 2.73 0.145 -13.3 13.0 8.057 123 60.00 .45. ...
[2]
181 -100 -94 -14 -14 14.8 -7.282 -7.736 13.7 123 60.01 .45. ...
-1.97 159 -160 -2.62 -2.57 -0.250 13.3 -12.9 -8.154 123 60.01 .45. ...
-181 99 95 14 14 -14.8 7.190 7.822 -13.6 123 60.01 .45. ...
3.14 -160 159 2.52 2.54 0.347 -13.4 12.9 8.243 123 60.01 .45. ...
Output, Input, and Protection, and Control Columns
Table 12.3 summarizes the event report output, input, protection and control
columns. See Table 9.6 for more information on Relay Word bits shown in
Table 12.3.
Some of the column definitions are different for wye-connected PT
applications (global setting PTCONN = WYE) and delta-connected PT
applications (global setting PTCONN = DELTA). These differences are noted
in Table 12.3. Figure 12.3 shows a wye-connected example event report, and
Figure 12.4 shows a delta-connected example event report.
NOTE: The event report does not
show the output contacts (OUT201–
OUT212) or optoisolated inputs (IN201–
IN208) for the extra I/O board.
M
NOTE: The “V” option has no effect
for compressed event reports (EVE C)
because the analog values
automatically have variable scaling.
Variable scaling for compressed data
displays both currents less than 10 A
and voltages less than 10 kV with 3
decimal places.
M
Table 12.3 Output, Input, and Protection, and Control Element Event Report
Columns (Sheet 1 of 15)
Column Heading
Corresponding
Elements
(Relay Word Bits)
Symbol Definition
All columns • Element/input/output not picked
up or not asserted, unless other-
wise stated.
a
Out 12 OUT101, OUT102 1 Output contact OUT101 asserted.
2 Output contact OUT102 asserted.
b Both OUT101 and OUT102 asserted.
