2.10
SEL-351S Relay Instruction Manual Date Code 20080103
Installation
User-Configurable Label Option for the Front Panel
Figure 2.8 SEL-351S (Horizontal) Blank Slide-In Label Set and Label
Removal Tool
Blank Target LED Label
Blank
Operator
Control
Labels
Label Removal Tool
Key
196-0525
INSERT UNDER LABEL
PUSH IN ALL THE WAY
HOLD
LABEL
WITH
FINGER
HERE
PULL
WITH
OTHER
HAND
LABEL REMOVAL TOOL
196-0513 RIGHT
196-0513 LEFT
196-0513 LED
196-0513 TRIP/CLOSE
Blank Breaker
LED Label
