Installation
700-1014 R002 1–7
5. Fasten the mounting plate to the mounting surface with the four #10 × 1" self-
drilling screws.
6. Connect the rear bottom edge of the DVR to the spring tab on the rear edge of the
mounting tray.
7. Attach the front bottom edge to the front of the DVR using the two pan-head
Phillips 3/16" screws.
8. Connect the necessary cables and components.
9. Attach the cable cover to the DVR using the provided thumb screws.
6
4
4
4
4
6
5
Cable Cover
Thumb screws
