Installation
700-1014 R002 1–1
CHAPTER 1
Installation
This chapter describes the installation steps for the Trooper TL-HD DVR with
firmware version 2.1 or higher. This chapter contains the following sections:
Tools and Equipment, on page 1–1
Trooper TL-HD System Package Contents, on page 1–2
Installation Diagram, on page 1–3
Installation Best Practices, on page 1–4
Dimensions, on page 1–5
DVR and Component Installation, on page 1–6
DVR Installation, on page 1–6
Camera Installation, on page 1–8
Adapter Harness Installation, on page 1–10
Expansion Harness Installation (Optional), on page 1–10
SD Card Installation (Optional), on page 1–11
Power Pass Through Cable Installation (Optional), on page 1–13
Diagnostic Button Installation (Optional), on page 1–13
RGY Illuminator Installation (Optional), on page 1–13
12 Volt Installation Details, on page 1–14
Hardware Installation Final Checklist, on page 1–15
1.1. Tools and Equipment
This DVR system must be installed by a professional installer. A professional installer
has the experience and equipment to install and configure this DVR system to run
properly.
Check that you have all the system components and inspect the units for any scratches
or damage before installing.
Keys included in package contents:
• DVR keys for securing the removable hard drive
• Front cover keys for securing the removable front cover
Configuration equipment:
• For on-screen configuration: portable video monitor and trackball mouse
• For vMax Web configuration: laptop and an Ethernet cable
