13
MIDI
1. Connect the MIDI OUT jack to the MIDI input of the slave synthesizer, or other
MIDI device.
2. Connect the MIDI IN jack to the MIDI output of the other MIDI device. (When
dumping samples, this is optional but improves the dump speed and provides
error correction. For more information, see Section 8.)
3. Connect the MIDI OUT/THRU jack to the MIDI input of the other MIDI
equipment.
If the OUT/THRU switch is in the THRU position, the data output is identical to
the data appearing at the MIDI IN jack. If the switch is in the OUT position, the
data output is identical to the data appearing at the MIDI OUT jack.
All MIDI operations, including clock input and output, are explained in
Section 8.
LINE VOLTAGE SELECTION AND FUSING
CAUTION! Before connecting the power cord or switching power on, check
the line voltage selector as described below. Never switch the voltage selector
while power is connected.
1. Check that the voltage selector on the back panel matches your power source.
Prophet VS's shipped in the U.S., or to Canada or Japan are set to 110V.
Prophet VS's shipped to Europe, Australia, or New Zealand are set to 220V.
2. If the selected voltage does not match your line voltage, switch it.
WARNING! CHANGING THE VOLTAGE SELECTOR MAY REQUIRE THE
USE OF A DIFFERENT LINE CORD OR ATTACHMENT PLUG, OR BOTH. TO
REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REFER SERVICING TO
QUALIFIED PERSONNEL.
3. If you switched the voltage selector, change the fuse:
Voltage Fuse Rating
110V 1/2A (500 mA)
220V 1/4A (250 mA)
