Sharp SF-2040 - Sf-A55; Sf-S15; Sf-S53; Options Specifications

[3] OPTIONS SPECIFICATIONS
1. SF-A55
Name Reversing automatic document feeder
Original feed system Continuous auto feed
Document feed sequence Bottom take-up feeding (Face-up discharge)
Document transfer drive Belt drive
Orientation of document setting Face up
Document size A3 ∼ B5/W letter ∼ Invoice
Document weight
Thin paper mode: 35 ∼ 50g/m
2
(Japan only)
Standard mode: 51 ∼ 128g/m
2
Max. No. of documents to be
set
Max. 50 sheets (35 - 80g/m
2
)
(30 sheets for A3 or 11" × 17")
Function
Original reverse mechanism (duplex original)
SDF/ADF mode selection (selectable with the key
operator program. Japan only)
Original size detection mechanism
Thin film/standard mode selection (selectable with the
key operator program. Japan only)
Mixed paper feed
Random paper feed allowed
Power supply Supplied from the copier
Dimensions 600 (W) × 525 (D) × 170 (H)mm
Weight Approx. 15kg
2. SF-S15
Name 20-bin sorter
No. of bins 20 bins
Paper collection Copy face up
Capacity per bin Max. 50 sheets (100 sheets: Top bin)
Allowable paper size/weight
for collating
Max. A3, Min.: B5 (Min. A6 for non-sort)
Non-sort: 52 ∼ 128g/m
2
,
Sort/Grouping: 56 ∼ 80g/m
2
Power source Supplied from the copier.
Dimensions 500mm (W) × 520mm (D) × 957mm (H)
Weight About 13kg
3. SF-S53
Name Staple sorter
No. of bins 20 bins
Paper collection Copy face up
Capacity per bin Max. 50 sheets (250 sheets: Top bin)
Allowable paper size/weight
for collating
Max.: A3, Min.: B5 (Non-sort: Min. A5),
Non-sort: 52 ∼ 128g/m
2
,
Sort/staple sort/grouping: 56 ∼ 89g/m
2
No. of sheets for stapling 50 sheets (80g/m
2
)
Power source Supplied from the copier.
Dimensions 475mm (W) × 597mm (D) × 995mm (H)
Weight About 42.1kg
3 – 1
