Sharp SF-2040 - Paper Feed Unit

3. Paper feed unit
8 12
2 9 13
3 10 14
4 11
5
6
1
7
Paper feed
roller
Takeup roller Counter roller Solenoid
Unfasten the harness of the spring clutch.
Remove the manually set E-ring.
Move the clutch shaft to the location where the pickup roller lever
disengages from the frame.
Remove the manually set E-ring.
Remove the pickup roller lever.
Remove the paper feed roller.
NOTE:
Remove the takeup roller.
NOTE:
Remove the tension spring.
Remove the manually set
E-ring.
Move the shaft, including the
gearwheel.
Remove the counter roller.
Remove the spring.
Remove the solenoid lever.
Remove the solenoid
(on the line).
The one-way clutch is on
the rear frame side
(clutch side).
The side with a protrusion is
on the rear side.
6 – 5
