Shimadzu IRAffinity-1 User Manual

6-4
IRAffinity-1
Chapter 6 Troubleshooting
Error Message Meanings and Operation
A/D out of range Measured data beyond the A/D converter range limit. When
using standard detector, check if transmittance of the sample
is changed, or with MCT detector, reduce the light intensity
using the aperture, etc.
Interferogram beyond A/D converter limit Measured data beyond the A/D converter range limit. When
using standard detector, check if transmittance of the sample
is changed, or with MCT detector, reduce the light intensity
using the aperture, etc.
Offset value beyond A/D converter limit Measured data beyond the A/D converter range limit. When
using standard detector, check if transmittance of the sample
is changed, or with MCT detector, reduce the light intensity
using the aperture, etc.
No centerburst detected Centerburst of measured interferogram can not be detected.
Execute [Measurement]-[Auto Adjust].
Vertical value beyond the limit The parameters of fixed mirror beyond the software limit.
Execute [Measurement]-[Auto Adjust].
Horizontal value beyond the limit The parameters of fixed mirror beyond the software limit.
Execute [Measurement]-[Auto Adjust].
Optim. vertical value beyond the limit after
[Auto Adjust]
The parameters of fixed mirror adjustment beyond the
software limit. Execute [Measurement]-[Auto Adjust].
Optim. horizontal value beyond the limit after
[Auto Adjust]
The parameters of fixed mirror adjustment beyond the
software limit. Execute [Measurement]-[Auto Adjust].
Fixed mirror adjustment failed. Fixed mirror adjustment has failed. Execute [Measurement]-
[Auto Adjust].
No interferogram FFT in manipulation must be executed to IFG data.
Recalculation can not be performed (no
data)
There is no data for recalculate. Reload the data to be
recalculated.
ASC-A initialization error Error occurs when initializing Auto sample changer
connected to the connector A. Confirm the connection of
ASC.
ASC-B initialization error Error occurs when initializing Auto sample changer
connected to the connector B. Confirm the connection of
ASC.
Selected ASC is not detected. Selected ASC is not detected. ASC cable might be
disconnected.
Failure in initializing of ASC motor System fails initialization of ASC motor. Check the
connection of ASC cable.
Failure in initializing of Beam setting motor System fails initialization of Beam switching motor. Please
contact your SHIMADZU representative.
Lamp offline Light source inoperative. Please contact your SHIMADZU
representative.
