xx
Consumables and maintenance parts
No.
P/N
Part name
Replacement
interval
Recommended
number of parts
1
211-74362
Electrode D6 x 100
*
1
5000 emissions
4 pcs
2
036-11204
O-ring 4D P6
*
2
1 month
10 pcs
3
042-60424-23
Fan 4710PS-20T-B30-B00
*
3
2 - 3 years
3 pcs
4
042-60474-01
Fan 4715MS-10T-B50-B00
2 - 3 years
3 pcs
5
065-80826-06
Relay MY4N AC200V
*
4
1 year
1 pc
6
065-60648-11
Relay LY2N DC24V
*
4
1 year
5 pcs
7
065-60848-02
Relay LY4N DC24V
*
4
1 year
3 pcs
8
211-76668
Dust cup
When damaged
1 pc
9
211-74359-03
*
5
Sample plate
(hole diameter 12mm)
When damaged
1 pc
10
211-74439
Electrode holder assembly
When damaged
1 pc
11
211-51031
Sample holder assembly
*
6
When damaged
1 pc
12
211-74965
*
7
Brush
When damaged
1 pc
13
017-30159-03
Rotary pump oil MR-200 1L
6 months
1 can
14
239-07003-08
Molecular sieves 13 x 4 x 8M
1 year
1 bottle
15
017-30813-01
Silicon grease HIVAC-G
1 can
*
1
5000 emissions is a typical value. Electrode can be used until its length reduces to 65 mm.
(in the case used with automatic electrode cleaning unit, 82mm)
*
2
Replacement interval varies depending on the frequency of analysis. 1 month is a typical
value.
*
3
There are three No.3 Fans used in PDA-7000.
The one used in excitation source unit has to be replaced once every two years.
The other two attached on the right side panel have to be replaced once every three years.
*
4
Relays have to be replaced on an annual inspection.
*
5
Turn sample plate upside down after every spark stand cleanup.
*
6
The lifetime of the sample holder varies depending on how it is used.
For example, if it is used with the flexure of the plate spring around 10mm, the expected
lifetime is about 8000-times use. In the case of around 5mm, it is about 24000-times use.
*
7
The spare head for brush 211-74663-91.
